Newton IR 2
Infrared Fill Level Control
The miho Newton IR 2 checks fill level for underfilling and overfilling in glass and PET bottles using infrared absorption measurement with two independently adjustable measuring spots. It requires no ionising radiation, has a compact build, and optionally inspects cap presence.
Fill Level Control (Infrared Technology)
The miho Newton IR 2 checks fill level for any underfilling and overfilling in glass and PET bottles, with easy handling. Inspection is carried out using an infrared measuring method (absorption), via two independently adjustable measuring spots. Optionally, the bottle can also be inspected for cap presence.
Key Features
- No ionising radiation.
- Compact construction.
- Any filling product.
- Two independently adjustable infrared measuring spots.
- Optional cap presence inspection.
- Comprehensive statistics for individual fault types.
- Serial fault detection implemented.
- Optional connection to external production data acquisition system.
- Handwheel height adjustment for bottle type changes.
- Overfilling measurement point independently adjustable from underfilling measurement point.
Limitations
Not suitable for bottles labelled at the fill level, or swing-top bottles with a fill level at the bracket area.
Applications
Typically installed at the filler outfeed or labelling machine outfeed — ideal for reliable, radiation-free fill level verification across glass and PET bottles with any filling product.
Talk to the Techotrix team to find out whether the miho Newton IR 2 is the right fill level control solution for your line.
| Detection Method | Infrared absorption (two measuring spots) |
| Radiation | None (no ionising radiation) |
| Compatible Containers | Glass and PET bottles |
| Adjustment | Handwheel height adjustment; independently adjustable over/underfill points |
| Placement | Filler outfeed or labeller outfeed |
| Not Suitable For | Fill-level labelled bottles, swing-top bottles with bracket-area fill level |
Optional accessories for the miho Newton IR 2:
- Cap Presence Detection.
- External Production Data Acquisition Connection.
Contact the Techotrix team to confirm the right Newton IR 2 configuration for your line.
