PSC-A10F Series

Pyrometer for Measuring Through Hot Combustion Gases

The digital PSC-A10F pyrometer series is designed to measure temperature through hot combustion gases and clean flames. At a wavelength of 3.9µm, hot combustion furnace gases and clean burning flames are transparent, allowing these pyrometers to accurately measure targets even inside a flame or gas-filled furnace. Temperature ranges span 200°C to 2500°C.

Key Features

• Fast response time of just 1 millisecond.
• Three sighting methods: laser, through-lens, or video camera.
• Choice of four variable focus optics.
• Outputs 0/4-20mA and RS485 Modbus RTU.
• On-board temperature display with push-button parameter adjustment, or PC configuration via PSC Spot software.
• Choice of rugged protective hardware for harsh environments.

Applications

Purpose-built for power and recovery boilers, measuring through clean flame and combustible gases, composites, and research and development applications where standard pyrometers would be blocked or distorted by combustion by-products.

Talk to the Techotrix team to find out whether the PSC-A10F is the right fit for your application.
